| Part ID: |
Part Number: |
Part Desc: |
Remark: |
Qty: |
Price: |
| 1 |
90201-12790 |
WASHER, PLATE |
|
|
YEN 160.00 |
| 2 |
8CC-85790-01 |
THERMOSENSOR ASSY |
|
|
YEN 4,800.00 |
| 3 |
5VY-81673-00 |
ROTOR |
|
|
--- |
| 4 |
90282-03001 |
KEY, STRAIGHT |
|
|
--- |
| 5 |
90201-103U4 |
WASHER, PLATE |
|
|
--- |
| 6 |
90105-10290 |
BOLT, FLANGE |
|
|
YEN 400.00 |
| 7 |
5VY-85820-00 |
SERVO MOTOR ASSY |
|
|
--- |
| 8 |
5VY-85829-00 |
COVER, SERVO MOTOR |
|
|
--- |
| 9 |
97707-50514 |
SCREW, TAPPING |
|
|
--- |
| 10 |
5VX-82380-00 |
SENSOR, PRESSURE |
|
|
--- |
| 11 |
97707-50020 |
SCREW, TAPPING |
|
|
--- |
| 12 |
5VY-82310-00 |
IGNITION COIL ASSY |
|
|
--- |
| 13 |
5VY-82309-00 |
WIRE, SUB LEAD |
|
|
--- |
| 14 |
3GB-82540-01 |
NEUTRAL SWITCH ASSY |
|
|
YEN 1,360.00 |
| 15 |
90430-10148 |
GASKET |
|
|
YEN 160.00 |
| 16 |
5VY-85720-00 |
OIL LEVEL GAUGE ASSY |
|
|
--- |
| 17 |
95027-06016 |
BOLT, FLANGE |
|
|
YEN 160.00 |
| 18 |
90465-08013 |
CLAMP |
|
|
--- |
| 19 |
4XV-83755-02 |
SENSOR, SPEED |
|
|
--- |
| 20 |
90464-51001 |
CLAMP |
|
|
--- |
| 21 |
90110-06041 |
BOLT, HEXAGON SOCKET HEAD |
|
|
YEN 80.00 |
| 22 |
90465-08028 |
CLAMP |
|
|
--- |
| 23 |
5VY-81670-00 |
PICK-UP ASSY |
|
|
--- |
| 24 |
5VY-15589-00 |
PLATE, CLUTCH COVER |
|
|
--- |
| 25 |
90110-06041 |
BOLT, HEXAGON SOCKET HEAD |
|
|
YEN 80.00 |
| 26 |
90465-08191 |
CLAMP |
|
|
--- |
| 27 |
5VY-85896-00 |
SENSOR, CAM POSITION |
|
|
YEN 9,600.00 |
| 28 |
90110-06117 |
BOLT, HEXAGON SOCKET HEAD |
|
|
--- |
