| Part ID: |
Part Number: |
Part Desc: |
Remark: |
Qty: |
Price: |
| 1 |
45S-XF171-00-P0 |
COVER, SIDE 1 |
|
|
--- |
| 2 |
21C-F172A-00-P1 |
PANEL 1 |
|
|
--- |
| 3 |
90183-05818 |
NUT, SPRING |
|
|
--- |
| 4 |
97707-50012 |
SCREW, TRUSS HEAD TAPPING |
|
|
YEN 80.00 |
| 5 |
45S-XF172-00-P0 |
COVER, SIDE 2 |
|
|
--- |
| 6 |
21C-F172F-00-P1 |
PANEL 2 |
|
|
--- |
| 7 |
90183-05818 |
NUT, SPRING |
|
|
--- |
| 8 |
97707-50012 |
SCREW, TRUSS HEAD TAPPING |
|
|
YEN 80.00 |
| 9 |
21C-F1717-00 |
DAMPER |
|
|
--- |
| 10 |
5DG-F1778-00 |
DAMPER, LOCATING 1 |
|
|
--- |
| 11 |
21C-XF173-60-33 |
COVER, SIDE 3 |
|
|
--- |
|
21C-XF173-70-33 |
COVER, SIDE 3 |
|
|
--- |
| 12 |
21C-XF174-60-33 |
COVER, SIDE 4 |
|
|
--- |
|
21C-XF174-70-33 |
COVER, SIDE 4 |
|
|
--- |
| 13 |
90183-05818 |
NUT, SPRING |
|
|
--- |
| 14 |
97707-50012 |
SCREW, TRUSS HEAD TAPPING |
|
|
YEN 80.00 |
| 15 |
21C-XF17C-70-33 |
COVER, SIDE 5 |
|
|
--- |
| 16 |
5TS-F836B-02 |
.TUNING FORK MARK |
|
|
--- |
| 17 |
97707-50012 |
SCREW, TRUSS HEAD TAPPING |
|
|
YEN 80.00 |
| 18 |
98507-06012 |
SCREW, PAN HEAD |
|
|
YEN 80.00 |
| 19 |
90119-06044 |
BOLT, WITH WASHER |
|
|
--- |
| 20 |
92017-06016 |
BOLT, BUTTON HEAD |
|
|
YEN 80.00 |
| 21 |
90201-06055 |
WASHER, PLATE |
|
|
--- |
| 22 |
90480-01559 |
GROMMET |
|
|
--- |
